Metal Etch Scrubber
Meta Etch Scrubber
Traditionally etching was performed by hand. It was implemented by using sharp tipped tool to etch metal according to desired design pattern. This process is time consumable. Nowadays the most popular metal etching is acid etching as the chemical technology has improved, since chemical milling is much faster than mechanical milling. Metal etching is process of creating design on metal surface using acid or mordant. The most commonly used chemicals are nitric acid, hydrochloric acid, potassium chlorate and Ferric Chloride. These acids will be used in different concentrations.
Product Catalogue
Description
Metal Etch Scrubber
Meta Etch Scrubber
Traditionally etching was performed by hand. It was implemented by using sharp tipped tool to etch metal according to desired design pattern. This process is time consumable. Nowadays the most popular metal etching is acid etching as the chemical technology has improved, since chemical milling is much faster than mechanical milling. Metal etching is process of creating design on metal surface using acid or mordant. The most commonly used chemicals are nitric acid, hydrochloric acid, potassium chlorate and Ferric Chloride. These acids will be used in different concentrations.
Metal etching Types
- Acid etching
- Aluminium etching
- Brass etching
- Chemical etching
- Copper etching
- Photo etching
The acids used in metal etching are extremely corrosive and the fume generated from the process attack all tissues of the body.
Apzem approach is to eliminate acid fumes from your process using adsorption technology. Specialized adsorption media will be used to get higher removal capacity rather than normal media. The saturated media can be disposed easily in non-hazardous landfills. The scrubber is available as portable and centralized scrubber system based on conditions and requirements.
Features of Meta Etch Scrubber
- Performance Guaranteed
- Low maintenance
- Low pressure drop, Minimal energy cost
- No water, ETP is not required
- No hazardous by-product
- Chemical Reactor vents
- Laboratory
- Hospital
- Food processing area
- Storage tank vent
- Air flow rate from 50 CFM to 2000 CFM
- Concentration: 1 ppm to 200 ppm (continuous) up to 2000 ppm (Intermittent)
- Removal efficiency: up to 99.99 %
- Material of Construction: MS with Epoxy lining
- Construction: Heavy Gauge, Fully welded cabinet, robust construction
Dimensions
| Model | Air flow rate (CFM) | Dimension
Diameter (mm) |
Height (mm) |
| ADS-30 | 100 | 300 | 1400 |
| ADS-45 | 300 | 450 | 1500 |
| ADS-60 | 500 | 600 | 1500 |
| ADS-75 | 800 | 750 | 1650 |
| ADS-90 | 1000 | 900 | 1700 |
| ADS-105 | 1500 | 1050 | 2000 |
| ADS-120 | 2000 | 1200 | 2200 |
https://www.apzem.in/index.php/product/metal-etch-scrubber/
Blower: Direct drive, High efficiency, Low noise
